Residual Current Devices (RCDs) – also known in the U.S. as Ground-Fault Circuit Interrupters (GFCIs) or Residual Current Circuit Breakers (RCCBs) – are essential safety components in electrical systems. They protect people and property by cutting off power when a ground fault or leakage current is detected. But not all RCDs are the same. The most common types are Type AC, Type A, and Type B, and each is designed to detect different kinds of fault currents. Understanding the differences helps ensure that your electrical system is both safe and compliant with modern standards.
Here’s a breakdown of how each type works and where it should be used.
What Does an RCD Do?
An RCD continuously monitors the current flowing through a circuit. Under normal conditions, the current going out through the hot (live) conductor is equal to the current returning through the neutral. If a fault occurs – for example, if electricity flows through a person or to ground – this balance is disturbed. The RCD detects the imbalance and disconnects the circuit within milliseconds.
This rapid response can prevent serious electric shock and reduce the risk of electrical fires.
Type AC – The Basic Model
Type AC RCDs respond only to alternating current (AC) faults. They were once the standard type used in many installations, especially before electronic devices became widespread.
However, in modern systems, Type AC devices are considered outdated. Many appliances today – such as washing machines, LED lighting, and power supplies – contain electronic components that can generate direct current (DC) leakage. These DC components can “blind” a Type AC RCD, preventing it from tripping when it should.
In the U.S., Type AC devices are rarely used in new installations. If you find one in an older system, it’s a good idea to have it evaluated and possibly replaced with a more advanced type.
Type A – The Modern Standard
Type A RCDs are now the most common choice for residential and light commercial installations. They detect both AC faults and pulsating DC faults, which are typical in appliances with electronic controls.
Type A devices provide reliable protection in circuits that supply:
- Washing machines and dryers
- Induction cooktops
- Heat pumps and HVAC systems
- EV chargers for plug-in hybrids
- LED lighting and electronic power supplies
In the U.S., GFCIs and combination AFCI/GFCI breakers used in homes generally provide protection equivalent to Type A. They are the recommended standard for most modern installations, offering a good balance between safety, compatibility, and cost.
Type B – For Advanced DC Applications
Type B RCDs are the most sophisticated type. They can detect AC, pulsating DC, and smooth DC (pure direct current) faults. This makes them essential in systems where significant DC components may be present – situations where Type A devices might fail to operate correctly.
Typical applications include:
- Electric vehicle charging stations (Level 2 and DC fast chargers)
- Solar photovoltaic (PV) systems with inverters
- Variable frequency drives (VFDs) in industrial equipment
- Large heat pumps and HVAC systems with advanced electronics
Type B RCDs are more expensive, but in these installations, they are critical for safety. Many equipment manufacturers specifically require a Type B device to ensure proper protection and compliance with standards such as UL 1053 or IEC 62423.
Læs også:
Choosing the Right Type
Selecting the correct RCD depends on the type of load and the presence of electronic equipment:
- Older installations without electronics: Type AC (though replacement is recommended).
- Typical modern home or office: Type A (or equivalent GFCI/AFCI).
- Systems with EV chargers, solar inverters, or industrial drives: Type B.
If you’re unsure which type you need, consult a licensed electrician. They can assess your system and ensure that the protective devices meet both safety requirements and local electrical codes, such as the National Electrical Code (NEC) in the U.S.
Maintenance and Testing
Even the best RCD needs occasional attention. Most units have a test button that should be pressed a few times a year. When pressed, the device should trip immediately. If it doesn’t, it may need to be replaced.
It’s also wise to have your electrical system inspected whenever you add new equipment, such as a solar array or EV charger. Ensuring that your RCDs are properly rated and functioning is one of the simplest and most effective ways to protect people and property from electrical hazards.
In Summary
- Type AC: Detects only AC faults – outdated for modern systems.
- Type A: Detects AC and pulsating DC faults – standard for most homes.
- Type B: Detects all fault types, including smooth DC – required for EV chargers, solar, and industrial equipment.
Choosing the right RCD isn’t just about meeting code requirements; it’s about ensuring that your electrical system provides reliable protection in a world where electronics and DC power are everywhere.
